Category
Lathes - Shaft Type
Manufacturer
American
Model
Pacemaker
Serial Number
75158-56
Year
1956 / New Retrofit
Swing Over Bed
33.00
in
838.20
mm
Swing Over Cross Slide
19.00
in
482.60
mm
Distance Between Centers
154.00
in
3911.60
mm
X – Cross Slide Travel
16.00
in
406.40
mm
Z – Carriage Travel
148.00
in
3759.20
mm
Turret 1
4-Sided Indexing Tool Post
Chuck Diameter
24.00
in
609.60
mm
Chuck Type
4-Jaw Independent with Integral Master Jaw and Reversible Bolt-On Top Jaws, Cushman 10 004 24 L03D
Spindle Bore
2.81
in
71.37
mm
Spindle Power
40.00
hp
29.83
kW
Spindle Speed
9 - 900 RPM 27 Steps
Spindle Nose
L3
Tailstock Quill Diameter
5.00
in
127.00
mm
Ways
Hardened Replaceable BD Ways
Power
3PH / 60 Hz / 480 Volt Existing
Additional
Taper attachment, heavy duty steady rest with 16 1/2 in (415 mm) capacity, ways reground, carriage re-scraped, tailstock aligned
Machine Length
305.00
in
7747.00
mm
Machine Width
90.00
in
2286.00
mm
Machine Height
65.00
in
1651.00
mm
Condition
Excellent
