Category
Mills - Vertical Traveling Gantry Type
Manufacturer
Asquith VNC
Model
3500 / 2250
Year
1980s / New Retrofit
Control
New Fanuc 18iMB
X - Gantry Travel
134.00
in
3403.60
mm
Y - Saddle
92.00
in
2336.80
mm
Z – Spindle Travel
12.00
in
304.80
mm
W – Crossrail Travel
Fixed
Distance Between Columns
90.87
in
2308.10
mm
Rapid Travel Speed
200.00
in
5080.00
mm
Distance from Spindle to Table
40.00
in
1016.00
mm
Spindle Power
60.00
hp
44.74
kW
Spindle Taper
50
Spindle Drawbar
Power
Ways
Hardened
Way Covers
Yes, Steel Telescopic
Power
3 PH / 50-60Hz / 200, 380, 440 V
Additional
New servo motors, servo drives and spindle drive
Table Length
87.72
in
2228.09
mm
Table Width
137.80
in
3500.12
mm
Table Capacity
100000.00
lbs
45359.20
kg
Condition
Excellent
Warranty
Manufacturer's warranty on new CNC, one year on replaced parts
