Category

Lathes – Gap Bed

Manufacturer

Takisawa

Model

Type B

Serial Number

AS97581

Year

1969

Chuck Type

Three jaw universal

Chuck Diameter

12.50

in

317.50

mm

Swing Over Bed

18.00

in

457.20

mm

Swing Over Crosslide

10.00

in

254.00

mm

Distance Between Centers

60.00

in

1219.20

mm

Swing In Gap

24.00

in

609.60

mm

Spindle Bore

2.00

in

44.45

mm

Spindle Power

7.50

hp

5.59

kW

Spindle Speed

35 - 1600 RPM

Spindle Nose

L-2

Tailstock Quill Diameter

2.38

in

60.45

mm

Tailstock Taper

4 MT

Thread Range

2 - 56 TPI / 0.25 – 3.75 Metric

Coolant

Yes

Power

3 Phase, 50-60 Hz, 200 - 500 Volts, existing

Additional

Quick change tool post front and rear, full length tracer, hardened ways, removable gap

Machine Weight

7100.00

lbs

1590.91

kg

Condition

Excellent, toolroom use only
